Coaxial surge protector DC-7 GHz

P8AX25-6G-N/FF
P8AX25-6G-N/FF
Part Number: 68014
  • RF coaxial surge protector
  • DC-7 GHz
  • 240 W
  • Connectors : N
  • Low insertion loss
  • Removale GDT
  • DC-pass
  • Bi-directional protection



Frequency range f DC-7 GHz
Insertion loss < 0.2 dB
Return loss > 19 dB
Impedance 50 ohms
VSWR <1.25:1
Max. load current IL 10 A
Operating current Ic None
Max. discharge current Imax 20 kA
Protection mode(s) Common mode
Protection level Up < 2300 V
Impulse current Iimp 1 kA
Nominal discharge current In 5 kA
Max Power 240 W
Typical let through energy 2.2 mJ
DC Pass ZERTZAERTZERTZER True
Insulation resistance IR ≥10 GOhms
Technology Gas discharge tube
Connection to Network Connector N Female/Female
Mounting Feedthrough
Housing material Brass/Surface plating : Cu Zn Sn
Operating temperature Tu -40/+85°C
Protection rating IP66
Outdoor application Yes
Failsafe mode Short-circuit
Disconnection indicator Transmission interrupt
Spare module(s) 1 x BA HF
Dimensions See diagram
Contacts Bronze/Surface Au-Ag
Weight 0.165 kg
Standards compliance IEC 61643-21 / EN 61643-21 / UL497C / UL497E
RohS compliance Yes
